Specification / Model No: 192

Extruder
Content	Specification
Screw diameter	A:Ø120mm	B:Ø100mm
Screw L/D ratio	A: 32:1	B:32:1
Barrel temperature control	A: 7 zones	B: 5 zones
Motor	A: 125HP	B: 100HP
Screen changer	1 set
Output	250 ~ 350kg/hr
T-Die width	1700mm
Finished product width	1574mm
Finished product thickness	0.1 ~ 0.25mm
Temperature control	14 zones
Rewinder unit	1 set
Preheating, embossing and cooling unit	1 set
Winder	1 set
Electricity control cabinet	Adopt SSR and PLC control system
Total weight	30 tons approximately
Occupied ground area	11000mm x 10000mm x 3350mm (L x W x H)

PS.We can manufacture the machines according to customers' requests.
